GW FIT Range Accessories for electrical installation

GW FIT Range Accessories for electrical installation

Cable glands

Nylon cable glands - PG pitch - grey RAL 7035 - IP66
Nylon cable glands - PG pitch - grey RAL 7035 - IP66
Gewiss-code
PG pitch
Mounting hole Ø (mm)
For cables Ø (mm)

Gewiss-code GW52001
PG pitch 7
Mounting hole Ø (mm) 12.5
For cables Ø (mm) from 3 to 6
Ga
Gewiss-code GW52002
PG pitch 9
Mounting hole Ø (mm) 16
For cables Ø (mm) from 6 to 8
Ga
Gewiss-code GW52003
PG pitch 11
Mounting hole Ø (mm) 19
For cables Ø (mm) from 8 to 10.5
Ga
Gewiss-code GW52004
PG pitch 13.5
Mounting hole Ø (mm) 20
For cables Ø (mm) from 9 to 12.5
Ga
Gewiss-code GW52005
PG pitch 16
Mounting hole Ø (mm) 23
For cables Ø (mm) from 13 to 16
Ga
Gewiss-code GW52006
PG pitch 21
Mounting hole Ø (mm) 29
For cables Ø (mm) from 9 to 10/from 17 to 20
Ga
Gewiss-code GW52007
PG pitch 29
Mounting hole Ø (mm) 37
For cables Ø (mm) from 13.5 to 15/from 21 to 26
Ga
Gewiss-code GW52008
PG pitch 36
Mounting hole Ø (mm) 48
For cables Ø (mm) from 17 to 20/from 30 to 34
Ga
Gewiss-code GW52009
PG pitch 42
Mounting hole Ø (mm) 54
For cables Ø (mm) from 36 to 39/from 40 to 43
Ga
Gewiss-code GW52010
PG pitch 48
Mounting hole Ø (mm) 60
For cables Ø (mm) from 38 to 40/from 46 to 50
Ga
UITRUSTING EN OPMERKINGEN
Nylon cable glands - PG pitch - grey RAL 7035 - IP68
Nylon cable glands - PG pitch - grey RAL 7035 - IP68
Gewiss-code
PG pitch
Mounting hole Ø (mm)
For cables Ø (mm)

Gewiss-code GW52071
PG pitch 7
Mounting hole Ø (mm) 12.5
For cables Ø (mm) from 3.5 to 6.5
Ga
Gewiss-code GW52072
PG pitch 9
Mounting hole Ø (mm) 16
For cables Ø (mm) from 4 to 8
Ga
Gewiss-code GW52073
PG pitch 11
Mounting hole Ø (mm) 19
For cables Ø (mm) from 5 to 10
Ga
Gewiss-code GW52074
PG pitch 13.5
Mounting hole Ø (mm) 20
For cables Ø (mm) from 6 to 12
Ga
Gewiss-code GW52075
PG pitch 16
Mounting hole Ø (mm) 23
For cables Ø (mm) from 10 to 14
Ga
Gewiss-code GW52076
PG pitch 21
Mounting hole Ø (mm) 29
For cables Ø (mm) from 13 to 18
Ga
Gewiss-code GW52077
PG pitch 29
Mounting hole Ø (mm) 37
For cables Ø (mm) from 18 to 25
Ga
Gewiss-code GW52078
PG pitch 36
Mounting hole Ø (mm) 48
For cables Ø (mm) from 22 to 32
Ga
Gewiss-code GW52079
PG pitch 42
Mounting hole Ø (mm) 54
For cables Ø (mm) from 30 to 38
Ga
Gewiss-code GW52080
PG pitch 48
Mounting hole Ø (mm) 60
For cables Ø (mm) from 34 to 44
Ga
UITRUSTING EN OPMERKINGEN
Nylon cable glands - METRIC pitch - grey RAL 7035 - IP68
Nylon cable glands - METRIC pitch - grey RAL 7035 - IP68
Gewiss-code
ISO pitch
Mounting hole Ø (mm)
For cables Ø (mm)

Gewiss-code GW52042
ISO pitch 12x1.25
Mounting hole Ø (mm) 12
For cables Ø (mm) from 3 to 6.5
Ga
Gewiss-code GW52043
ISO pitch 16x1.5
Mounting hole Ø (mm) 16
For cables Ø (mm) from 5 to 10
Ga
Gewiss-code GW52044
ISO pitch 20x1.5
Mounting hole Ø (mm) 20
For cables Ø (mm) from 10 to 14
Ga
Gewiss-code GW52045
ISO pitch 25x1.5
Mounting hole Ø (mm) 25
For cables Ø (mm) from 13 to 18
Ga
Gewiss-code GW52046
ISO pitch 32x1.5
Mounting hole Ø (mm) 32
For cables Ø (mm) from 18 to 25
Ga
Gewiss-code GW52047
ISO pitch 40x1.5
Mounting hole Ø (mm) 40
For cables Ø (mm) from 22 to 32
Ga
Gewiss-code GW52048
ISO pitch 50x1.5
Mounting hole Ø (mm) 50
For cables Ø (mm) from 30 to 38
Ga
Gewiss-code GW52049
ISO pitch 63x1.5
Mounting hole Ø (mm) 63
For cables Ø (mm) from 35 to 44
Ga
UITRUSTING EN OPMERKINGEN
Nylon cable glands - PG pitch with housing for rigid conduit - grey RAL 7035 - IP66
Nylon cable glands - PG pitch with housing for rigid conduit - grey RAL 7035 - IP66
Gewiss-code
PG pitch
Mounting hole Ø (mm)
For external conduits (mm)
For cables Ø (mm)

Gewiss-code GW52024
PG pitch 13.5
Mounting hole Ø (mm) 20
For external conduits (mm) 16
For cables Ø (mm) from 9 to 12.5
Ga
Gewiss-code GW52025
PG pitch 16
Mounting hole Ø (mm) 23
For external conduits (mm) 20
For cables Ø (mm) from 13 to 16
Ga
Gewiss-code GW52026
PG pitch 21
Mounting hole Ø (mm) 29
For external conduits (mm) 25
For cables Ø (mm) from 9 to 10/from 17 to 20
Ga
Gewiss-code GW52027
PG pitch 29
Mounting hole Ø (mm) 37
For external conduits (mm) 32
For cables Ø (mm) from 13.5 to 15/from 21 to 26
Ga
Gewiss-code GW52028
PG pitch 36
Mounting hole Ø (mm) 48
For external conduits (mm) 40
For cables Ø (mm) from 17 to 20/from 30 to 34
Ga
Gewiss-code GW52029
PG pitch 42
Mounting hole Ø (mm) 54
For external conduits (mm) 50
For cables Ø (mm) from 36 to 39/from 40 to 43
Ga
UITRUSTING EN OPMERKINGEN
Nylon cable glands - PG pitch - grey RAL 7035 - IP54
Nylon cable glands - PG pitch - grey RAL 7035 - IP54
Gewiss-code
PG pitch
Mounting hole Ø (mm)
For cables Ø (mm)

Gewiss-code GW52081
PG pitch 7
Mounting hole Ø (mm) 12.5
For cables Ø (mm) from 4 to 6
Ga
Gewiss-code GW52082
PG pitch 9
Mounting hole Ø (mm) 16
For cables Ø (mm) from 4.5 to 7
Ga
Gewiss-code GW52083
PG pitch 11
Mounting hole Ø (mm) 19
For cables Ø (mm) from 6 to 9
Ga
Gewiss-code GW52084
PG pitch 13.5
Mounting hole Ø (mm) 20
For cables Ø (mm) from 9 to 12
Ga
Gewiss-code GW52085
PG pitch 16
Mounting hole Ø (mm) 23
For cables Ø (mm) from 11 to 14
Ga
Gewiss-code GW52086
PG pitch 21
Mounting hole Ø (mm) 29
For cables Ø (mm) from 14 to 18
Ga
Gewiss-code GW52087
PG pitch 29
Mounting hole Ø (mm) 37
For cables Ø (mm) from 18 to 25
Ga
Gewiss-code GW52088
PG pitch 36
Mounting hole Ø (mm) 48
For cables Ø (mm) from 26 to 32
Ga

Closure caps

Nylon closure caps - grey RAL 7035 - IP65
Nylon closure caps - grey RAL 7035 - IP65
Gewiss-code
Pitch

Gewiss-code GW52361
Pitch PG7
Ga
Gewiss-code GW52362
Pitch PG9
Ga
Gewiss-code GW52363
Pitch PG11
Ga
Gewiss-code GW52364
Pitch PG13.5
Ga
Gewiss-code GW52365
Pitch PG16
Ga
Gewiss-code GW52366
Pitch PG21
Ga
Gewiss-code GW52367
Pitch PG29
Ga
Gewiss-code GW52368
Pitch PG36
Ga
Gewiss-code GW52369
Pitch PG42
Ga
Gewiss-code GW52370
Pitch PG48
Ga
Gewiss-code GW52372
Pitch M12
Ga
Gewiss-code GW52373
Pitch M16
Ga
Gewiss-code GW52374
Pitch M20
Ga
Gewiss-code GW52375
Pitch M25
Ga
Gewiss-code GW52376
Pitch M32
Ga
Gewiss-code GW52377
Pitch M40
Ga
Gewiss-code GW52378
Pitch M50
Ga
Gewiss-code GW52379
Pitch M63
Ga
UITRUSTING EN OPMERKINGEN
O-ring for closure caps
O-ring for closure caps
Gewiss-code
For caps with pitch

Gewiss-code GW52441
For caps with pitch PG7
Ga
Gewiss-code GW52442
For caps with pitch PG9
Ga
Gewiss-code GW52443
For caps with pitch PG11
Ga
Gewiss-code GW52444
For caps with pitch PG13.5
Ga
Gewiss-code GW52445
For caps with pitch PG16
Ga
Gewiss-code GW52446
For caps with pitch PG21
Ga
Gewiss-code GW52447
For caps with pitch PG29
Ga
Gewiss-code GW52448
For caps with pitch PG36
Ga
Gewiss-code GW52449
For caps with pitch PG42
Ga
Gewiss-code GW52450
For caps with pitch PG48
Ga
Gewiss-code GW52452
For caps with pitch M12
Ga
Gewiss-code GW52453
For caps with pitch M16
Ga
Gewiss-code GW52454
For caps with pitch M20
Ga
Gewiss-code GW52455
For caps with pitch M25
Ga
Gewiss-code GW52456
For caps with pitch M32
Ga
Gewiss-code GW52457
For caps with pitch M40
Ga
Gewiss-code GW52458
For caps with pitch M50
Ga
Gewiss-code GW52459
For caps with pitch M63
Ga

Fixing nuts

Nylon fixing nuts - Grey RAL 7035
Nylon fixing nuts - Grey RAL 7035
Gewiss-code
Pitch

Gewiss-code GW52341
Pitch PG7
Ga
Gewiss-code GW52342
Pitch PG9
Ga
Gewiss-code GW52343
Pitch PG11
Ga
Gewiss-code GW52344
Pitch PG13.5
Ga
Gewiss-code GW52345
Pitch PG16
Ga
Gewiss-code GW52346
Pitch PG21
Ga
Gewiss-code GW52347
Pitch PG29
Ga
Gewiss-code GW52348
Pitch PG36
Ga
Gewiss-code GW52349
Pitch PG42
Ga
Gewiss-code GW52350
Pitch PG48
Ga
Gewiss-code GW52352
Pitch M12
Ga
Gewiss-code GW52353
Pitch M16
Ga
Gewiss-code GW52354
Pitch M20
Ga
Gewiss-code GW52355
Pitch M25
Ga
Gewiss-code GW52356
Pitch M32
Ga
Gewiss-code GW52357
Pitch M40
Ga
Gewiss-code GW52358
Pitch M50
Ga
Gewiss-code GW52359
Pitch M63
Ga

Couplings and cable-glands

Shockproof polymer conduit/box couplings Grey RAL 7035
Shockproof polymer conduit/box couplings Grey RAL 7035
Gewiss-code
For external conduits (mm)
Mounting hole Ø (mm)
IP with rigid conduit
IP with corrugated conduit

Gewiss-code GW50415
For external conduits (mm) 16
Mounting hole Ø (mm) 20
IP with rigid conduit IP66
IP with corrugated conduit IP54
Ga
Gewiss-code GW50416
For external conduits (mm) 20
Mounting hole Ø (mm) 23
IP with rigid conduit IP66
IP with corrugated conduit IP54
Ga
Gewiss-code GW50417
For external conduits (mm) 25
Mounting hole Ø (mm) 29
IP with rigid conduit IP66
IP with corrugated conduit IP54
Ga
Gewiss-code GW50418
For external conduits (mm) 32
Mounting hole Ø (mm) 37
IP with rigid conduit IP66
IP with corrugated conduit IP54
Ga
Gewiss-code GW50419
For external conduits (mm) 40
Mounting hole Ø (mm) 48
IP with rigid conduit IP66
IP with corrugated conduit IP44
Ga
Gewiss-code GW50420
For external conduits (mm) 50
Mounting hole Ø (mm) 54
IP with rigid conduit IP66
IP with corrugated conduit IP44
Ga
UITRUSTING EN OPMERKINGEN
Flexible polymer conduit/box couplings Grey RAL 7035 - IP44
Flexible polymer conduit/box couplings Grey RAL 7035 - IP44
Gewiss-code
For external conduits (mm)
Mounting hole Ø (mm)

Gewiss-code GW50421
For external conduits (mm) 16
Mounting hole Ø (mm) 23
Ga
Gewiss-code GW50422
For external conduits (mm) 20
Mounting hole Ø (mm) 23
Ga
Gewiss-code GW50423
For external conduits (mm) 20
Mounting hole Ø (mm) 29
Ga
Gewiss-code GW50424
For external conduits (mm) 25
Mounting hole Ø (mm) 29
Ga
Gewiss-code GW50425
For external conduits (mm) 32
Mounting hole Ø (mm) 37
Ga
Gewiss-code GW50426
For external conduits (mm) 40
Mounting hole Ø (mm) 37
Ga
Gewiss-code GW50427
For external conduits (mm) 50
Mounting hole Ø (mm) 48
Ga
UITRUSTING EN OPMERKINGEN

Cable glands

Nickel-plated brass cable glands - IP65
Nickel-plated brass cable glands - IP65
Gewiss-code
Type of pitch
Seals Ø (mm)

Gewiss-code GW76841
Type of pitch PG11
Seals Ø (mm) 7.5 / 10 / 12.5
Ga
Gewiss-code GW76842
Type of pitch PG13.5
Seals Ø (mm) 7.5 / 10 / 12.5
Ga
Gewiss-code GW76843
Type of pitch PG16
Seals Ø (mm) 7.5 / 10 / 12.5
Ga
Gewiss-code GW76844
Type of pitch PG21
Seals Ø (mm) 10 / 13 / 16 / 19
Ga
Gewiss-code GW76845
Type of pitch PG29
Seals Ø (mm) 18 / 21 / 24 / 27
Ga
Gewiss-code GW76846
Type of pitch PG36
Seals Ø (mm) 24 / 27 / 30 / 33
Ga
Gewiss-code GW76847
Type of pitch PG42
Seals Ø (mm) 30 / 33 / 36 / 39
Ga
Gewiss-code GW76848
Type of pitch M20
Seals Ø (mm) 4 / 7 / 10 / 13
Ga
Gewiss-code GW76849
Type of pitch M25
Seals Ø (mm) 8.5 / 11.5 / 14.5 / 17.5
Ga
Gewiss-code GW76850
Type of pitch M32
Seals Ø (mm) 16 / 19 / 22 / 25
Ga
Gewiss-code GW76851
Type of pitch M40
Seals Ø (mm) 23 / 26 / 29 / 32
Ga
Gewiss-code GW76852
Type of pitch M50
Seals Ø (mm) 30 / 33 / 36 / 39
Ga
UITRUSTING EN OPMERKINGEN
Nickel-plated brass cable glands - IP68
Nickel-plated brass cable glands - IP68
Gewiss-code
Type of pitch
For cables Ø (mm)

Gewiss-code GW76825
Type of pitch PG11
For cables Ø (mm) from 4 to 9
Ga
Gewiss-code GW76826
Type of pitch PG13.5
For cables Ø (mm) from 7 to 11
Ga
Gewiss-code GW76827
Type of pitch PG16
For cables Ø (mm) from 10 to 13
Ga
Gewiss-code GW76828
Type of pitch PG21
For cables Ø (mm) from 12 to 17
Ga
Gewiss-code GW76829
Type of pitch PG29
For cables Ø (mm) from 17 to 24
Ga
Gewiss-code GW76830
Type of pitch PG36
For cables Ø (mm) from 20 to 26 / from 27 to 34
Ga
Gewiss-code GW76897
Type of pitch PG42
For cables Ø (mm) from 32 to 36
Ga
Gewiss-code GW76894
Type of pitch M12
For cables Ø (mm) from 3 to 6.5
Ga
Gewiss-code GW76896
Type of pitch M16
For cables Ø (mm) from 4 to 9
Ga
Gewiss-code GW76831
Type of pitch M20
For cables Ø (mm) from 10 to 13
Ga
Gewiss-code GW76832
Type of pitch M25
For cables Ø (mm) from 12 to 17
Ga
Gewiss-code GW76833
Type of pitch M32
For cables Ø (mm) from 14 to 21
Ga
Gewiss-code GW76834
Type of pitch M40
For cables Ø (mm) from 19 to 27
Ga
Gewiss-code GW76835
Type of pitch M50
For cables Ø (mm) from 25 to 34
Ga
Gewiss-code GW76895
Type of pitch M63
For cables Ø (mm) from 34 to 48
Ga
UITRUSTING EN OPMERKINGEN

Extensions

Nickel-plated brass extensions - IP65
Nickel-plated brass extensions - IP65
Gewiss-code
Male thread
Female thread

Gewiss-code GW76865
Male thread PG11
Female thread PG13.5
Ga
Gewiss-code GW76866
Male thread PG13.5
Female thread PG16
Ga
Gewiss-code GW76867
Male thread PG16
Female thread PG21
Ga
Gewiss-code GW76868
Male thread PG21
Female thread PG29
Ga
Gewiss-code GW76869
Male thread PG29
Female thread PG36
Ga
Gewiss-code GW76870
Male thread M20
Female thread M25
Ga
Gewiss-code GW76871
Male thread M25
Female thread M32
Ga
Gewiss-code GW76872
Male thread M32
Female thread M40
Ga
Gewiss-code GW76873
Male thread M40
Female thread M50
Ga
UITRUSTING EN OPMERKINGEN

Closure caps

Nickel-plated brass closure caps - IP65
Nickel-plated brass closure caps - IP65
Gewiss-code
Type of pitch

Gewiss-code GW76980
Type of pitch PG11
Ga
Gewiss-code GW76981
Type of pitch PG13.5
Ga
Gewiss-code GW76982
Type of pitch PG16
Ga
Gewiss-code GW76983
Type of pitch PG21
Ga
Gewiss-code GW76984
Type of pitch PG29
Ga
Gewiss-code GW76985
Type of pitch PG36
Ga
Gewiss-code GW76986
Type of pitch PG42
Ga
Gewiss-code GW76972
Type of pitch M12
Ga
Gewiss-code GW76973
Type of pitch M16
Ga
Gewiss-code GW76975
Type of pitch M20
Ga
Gewiss-code GW76976
Type of pitch M25
Ga
Gewiss-code GW76977
Type of pitch M32
Ga
Gewiss-code GW76978
Type of pitch M40
Ga
Gewiss-code GW76979
Type of pitch M50
Ga
Gewiss-code GW76974
Type of pitch M63
Ga
UITRUSTING EN OPMERKINGEN

Fixing nuts

Nickel-plated brass fixing nuts
Nickel-plated brass fixing nuts
Gewiss-code
Type of pitch

Gewiss-code GW76957
Type of pitch PG11
Ga
Gewiss-code GW76958
Type of pitch PG13.5
Ga
Gewiss-code GW76959
Type of pitch PG16
Ga
Gewiss-code GW76960
Type of pitch PG21
Ga
Gewiss-code GW76961
Type of pitch PG29
Ga
Gewiss-code GW76962
Type of pitch PG36
Ga
Gewiss-code GW76963
Type of pitch PG42
Ga
Gewiss-code GW76966
Type of pitch M12
Ga
Gewiss-code GW76951
Type of pitch M16
Ga
Gewiss-code GW76952
Type of pitch M20
Ga
Gewiss-code GW76953
Type of pitch M25
Ga
Gewiss-code GW76954
Type of pitch M32
Ga
Gewiss-code GW76955
Type of pitch M40
Ga
Gewiss-code GW76956
Type of pitch M50
Ga
Gewiss-code GW76967
Type of pitch M63
Ga

Metal cable glands

ATEX cable glands in nickel-plated brass with PG-pitch and long thread - IP68
ATEX cable glands in nickel-plated brass with PG-pitch and long thread - IP68
Gewiss-code
Type of pitch
Mounting hole Ø (mm)
For cables Ø (mm)

Gewiss-code GW76901
Type of pitch PG7
Mounting hole Ø (mm) 12.5
For cables Ø (mm) from 3 to 6.5
Ga
Gewiss-code GW76902
Type of pitch PG9
Mounting hole Ø (mm) 16
For cables Ø (mm) from 4 to 8
Ga
Gewiss-code GW76903
Type of pitch PG11
Mounting hole Ø (mm) 19
For cables Ø (mm) from 5 to 10
Ga
Gewiss-code GW76904
Type of pitch PG13.5
Mounting hole Ø (mm) 20
For cables Ø (mm) from 6.5 to 12
Ga
Gewiss-code GW76905
Type of pitch PG16
Mounting hole Ø (mm) 23
For cables Ø (mm) from 7 to 12
Ga
Gewiss-code GW76906
Type of pitch PG21
Mounting hole Ø (mm) 29
For cables Ø (mm) from 13 to 18
Ga
Gewiss-code GW76907
Type of pitch PG29
Mounting hole Ø (mm) 37
For cables Ø (mm) from 18 to 25
Ga
Gewiss-code GW76908
Type of pitch PG36
Mounting hole Ø (mm) 48
For cables Ø (mm) from 22 to 32
Ga
Gewiss-code GW76909
Type of pitch PG42
Mounting hole Ø (mm) 54
For cables Ø (mm) from 32 to 38
Ga
Gewiss-code GW76910
Type of pitch PG48
Mounting hole Ø (mm) 60
For cables Ø (mm) from 37 to 44
Ga
UITRUSTING EN OPMERKINGEN
ATEX cable glands in nickel-plated brass with metric pitch and long thread - IP68
ATEX cable glands in nickel-plated brass with metric pitch and long thread - IP68
Gewiss-code
Type of pitch
Mounting hole Ø (mm)
For cables Ø (mm)

Gewiss-code GW76921
Type of pitch M12
Mounting hole Ø (mm) 12
For cables Ø (mm) from 3 to 6.5
Ga
Gewiss-code GW76922
Type of pitch M16
Mounting hole Ø (mm) 16
For cables Ø (mm) from 6 to 10
Ga
Gewiss-code GW76923
Type of pitch M20
Mounting hole Ø (mm) 20
For cables Ø (mm) from 10 to 14
Ga
Gewiss-code GW76924
Type of pitch M25
Mounting hole Ø (mm) 25
For cables Ø (mm) from 14 to 18
Ga
Gewiss-code GW76925
Type of pitch M32
Mounting hole Ø (mm) 32
For cables Ø (mm) from 20 to 25
Ga
Gewiss-code GW76926
Type of pitch M40
Mounting hole Ø (mm) 40
For cables Ø (mm) from 22 to 32
Ga
Gewiss-code GW76927
Type of pitch M50
Mounting hole Ø (mm) 50
For cables Ø (mm) from 32 to 38
Ga
Gewiss-code GW76928
Type of pitch M63
Mounting hole Ø (mm) 63
For cables Ø (mm) from 37 to 44
Ga
UITRUSTING EN OPMERKINGEN

Fixing nuts

Nickel-plated brass fixing nuts
Nickel-plated brass fixing nuts
Gewiss-code
Type of pitch

Gewiss-code GW76941
Type of pitch PG7
Ga
Gewiss-code GW76942
Type of pitch PG9
Ga
Gewiss-code GW76957
Type of pitch PG11
Ga
Gewiss-code GW76958
Type of pitch PG13.5
Ga
Gewiss-code GW76959
Type of pitch PG16
Ga
Gewiss-code GW76960
Type of pitch PG21
Ga
Gewiss-code GW76961
Type of pitch PG29
Ga
Gewiss-code GW76962
Type of pitch PG36
Ga
Gewiss-code GW76963
Type of pitch PG42
Ga
Gewiss-code GW76943
Type of pitch PG48
Ga
Gewiss-code GW76949
Type of pitch M12
Ga
Gewiss-code GW76951
Type of pitch M16
Ga
Gewiss-code GW76952
Type of pitch M20
Ga
Gewiss-code GW76953
Type of pitch M25
Ga
Gewiss-code GW76954
Type of pitch M32
Ga
Gewiss-code GW76955
Type of pitch M40
Ga
Gewiss-code GW76956
Type of pitch M50
Ga
Gewiss-code GW76950
Type of pitch M63
Ga

Fixings for conduits

Shockproof polymer saddle snap clip - Grey RAL 7035
Shockproof polymer saddle snap clip - Grey RAL 7035
Gewiss-code
For external conduits (mm)
Wall-conduit axis distance (mm)

Gewiss-code GW50601
For external conduits (mm) 16
Wall-conduit axis distance (mm) 20
Ga
Gewiss-code GW50602
For external conduits (mm) 20
Wall-conduit axis distance (mm) 22
Ga
Gewiss-code GW50603
For external conduits (mm) 25
Wall-conduit axis distance (mm) 24.5
Ga
Gewiss-code GW50604
For external conduits (mm) 32
Wall-conduit axis distance (mm) 28
Ga
Gewiss-code GW50628
For external conduits (mm) 40
Wall-conduit axis distance (mm) 32
Ga
Gewiss-code GW50629
For external conduits (mm) 50
Wall-conduit axis distance (mm) 37
Ga
UITRUSTING EN OPMERKINGEN
Shockproof polymer saddle collar clip - Grey RAL 7035
Shockproof polymer saddle collar clip - Grey RAL 7035
Gewiss-code
For external conduits (mm)
Wall-conduit axis distance (mm)

Gewiss-code GW50605
For external conduits (mm) 16
Wall-conduit axis distance (mm) 20
Ga
Gewiss-code GW50606
For external conduits (mm) 20
Wall-conduit axis distance (mm) 22
Ga
Gewiss-code GW50607
For external conduits (mm) 25
Wall-conduit axis distance (mm) 24.5
Ga
Gewiss-code GW50608
For external conduits (mm) 32
Wall-conduit axis distance (mm) 28
Ga
Gewiss-code GW50630
For external conduits (mm) 40
Wall-conduit axis distance (mm) 32
Ga
Gewiss-code GW50631
For external conduits (mm) 50
Wall-conduit axis distance (mm) 37
Ga
UITRUSTING EN OPMERKINGEN

Fixings for cables

Shockproof polymer clips with hardened steel pin - Grey RAL 7035
Shockproof polymer clips with hardened steel pin - Grey RAL 7035
Gewiss-code
Colour
For external conduits (mm)

Gewiss-code GW50610
Colour Grey RAL 7035
For external conduits (mm) 3-4
Ga
Gewiss-code GW50611
Colour Grey RAL 7035
For external conduits (mm) 5-6
Ga
Gewiss-code GW50612
Colour Grey RAL 7035
For external conduits (mm) 7-8
Ga
Gewiss-code GW50613
Colour Grey RAL 7035
For external conduits (mm) 9-10
Ga
Gewiss-code GW50614
Colour Grey RAL 7035
For external conduits (mm) 11-12
Ga
Gewiss-code GW50615
Colour Grey RAL 7035
For external conduits (mm) 13-14
Ga
Gewiss-code GW50616
Colour Grey RAL 7035
For external conduits (mm) 15-16
Ga
Gewiss-code GW50617
Colour Grey RAL 7035
For external conduits (mm) 19-20
Ga
Gewiss-code GW50618
Colour Grey RAL 7035
For external conduits (mm) 21-22
Ga
Gewiss-code GW50619
Colour Grey RAL 7035
For external conduits (mm) 25-26
Ga
Gewiss-code GW50620
Colour Grey RAL 7035
For external conduits (mm) 31-32
Ga
Gewiss-code GW50621
Colour White
For external conduits (mm) 5-6
Ga
Gewiss-code GW50622
Colour White
For external conduits (mm) 7-8
Ga

Collars in galvanized steel

Galvanised steel collars M6 thread with 2 screws
Galvanised steel collars M6 thread with 2 screws
Gewiss-code
For external conduits (mm)

Gewiss-code GW50801
For external conduits (mm) 10-11
Ga
Gewiss-code GW50802
For external conduits (mm) 12-13
Ga
Gewiss-code GW50803
For external conduits (mm) 14-15
Ga
Gewiss-code GW50804
For external conduits (mm) 16-17
Ga
Gewiss-code GW50805
For external conduits (mm) 19-20
Ga
Gewiss-code GW50806
For external conduits (mm) 21-22
Ga
Gewiss-code GW50807
For external conduits (mm) 25-26
Ga
Gewiss-code GW50808
For external conduits (mm) 31-32
Ga
Gewiss-code GW50809
For external conduits (mm) 38-40
Ga
Gewiss-code GW50810
For external conduits (mm) 48-50
Ga

Clips in galvanized steel

Galvanised steel clips hole 12x6 mm
Galvanised steel clips hole 12x6 mm
Gewiss-code
For external conduits (mm)

Gewiss-code GW50811
For external conduits (mm) 10-11
Ga
Gewiss-code GW50812
For external conduits (mm) 12-13
Ga
Gewiss-code GW50813
For external conduits (mm) 14-15
Ga
Gewiss-code GW50814
For external conduits (mm) 16-17
Ga
Gewiss-code GW50815
For external conduits (mm) 19-20
Ga
Gewiss-code GW50816
For external conduits (mm) 21-22
Ga
Gewiss-code GW50817
For external conduits (mm) 25-26
Ga
Gewiss-code GW50818
For external conduits (mm) 31-32
Ga
Gewiss-code GW50819
For external conduits (mm) 38-40
Ga
Gewiss-code GW50820
For external conduits (mm) 48-50
Ga
Galvanised steel U-bolts with two holes
Galvanised steel U-bolts with two holes
Gewiss-code
Hole dimension (mm)
For external conduits (mm)

Gewiss-code GW50821
Hole dimension (mm) 7x4
For external conduits (mm) 10-11
Ga
Gewiss-code GW50822
Hole dimension (mm) 7x4
For external conduits (mm) 12-13
Ga
Gewiss-code GW50823
Hole dimension (mm) 7x4
For external conduits (mm) 14-15
Ga
Gewiss-code GW50824
Hole dimension (mm) 7x4
For external conduits (mm) 16-17
Ga
Gewiss-code GW50825
Hole dimension (mm) 7x4
For external conduits (mm) 19-20
Ga
Gewiss-code GW50826
Hole dimension (mm) 7x4
For external conduits (mm) 21-22
Ga
Gewiss-code GW50827
Hole dimension (mm) 7x4
For external conduits (mm) 25-26
Ga
Gewiss-code GW50828
Hole dimension (mm) 10x6
For external conduits (mm) 31-32
Ga
Gewiss-code GW50829
Hole dimension (mm) 10x6
For external conduits (mm) 38-40
Ga
Gewiss-code GW50830
Hole dimension (mm) 10x6
For external conduits (mm) 48-50
Ga

Fixing straps

Dispenser case for electrical installation accessories

Drill milling cutter

UITRUSTING EN OPMERKINGEN

RK Unions - Grey RAL 7035

Coupling - IP40
Coupling - IP40
Gewiss-code
Conduits Ø (mm)

Gewiss-code DX40016
Conduits Ø (mm) 16
Ga
Gewiss-code DX40020
Conduits Ø (mm) 20
Ga
Gewiss-code DX40025
Conduits Ø (mm) 25
Ga
Gewiss-code DX40032
Conduits Ø (mm) 32
Ga
Gewiss-code DX40040
Conduits Ø (mm) 40
Ga
Gewiss-code DX40050
Conduits Ø (mm) 50
Ga
Gewiss-code DX40063
Conduits Ø (mm) 63
Ga
UITRUSTING EN OPMERKINGEN
Tight bend - IP40
Tight bend - IP40
Gewiss-code
Conduits Ø (mm)

Gewiss-code DX40116
Conduits Ø (mm) 16
Ga
Gewiss-code DX40120
Conduits Ø (mm) 20
Ga
Gewiss-code DX40125
Conduits Ø (mm) 25
Ga
Gewiss-code DX40132
Conduits Ø (mm) 32
Ga
Gewiss-code DX40140
Conduits Ø (mm) 40
Ga
Gewiss-code DX40150
Conduits Ø (mm) 50
Ga
Gewiss-code DX40163
Conduits Ø (mm) 63
Ga
UITRUSTING EN OPMERKINGEN

MORBIDX unions - Grey RAL 7035

Release coupling - IP67
Release coupling - IP67
Gewiss-code
Conduits Ø (mm)

Release narrow radius bend - IP67
Release narrow radius bend - IP67
Gewiss-code
Conduits Ø (mm)

Release conduit-box union - IP67
Release conduit-box union - IP67
Gewiss-code
Conduits Ø (mm)
ISO pitch
For holes Ø (mm)

Gewiss-code DX43216
Conduits Ø (mm) 16
ISO pitch M 16x1.5
For holes Ø (mm) 16
Ga
Gewiss-code DX43220
Conduits Ø (mm) 20
ISO pitch M 20x1.5
For holes Ø (mm) 20
Ga
Gewiss-code DX43225
Conduits Ø (mm) 25
ISO pitch M 25x1.5
For holes Ø (mm) 25
Ga
Gewiss-code DX43232
Conduits Ø (mm) 32
ISO pitch M 32x1.5
For holes Ø (mm) 32
Ga
Gewiss-code DX43240
Conduits Ø (mm) 40
ISO pitch M 40x1.5
For holes Ø (mm) 40
Ga
Gewiss-code DX43250
Conduits Ø (mm) 50
ISO pitch M 50x1.5
For holes Ø (mm) 50
Ga
Release conduit-sheath union - IP65
Release conduit-sheath union - IP65
Gewiss-code
Conduits Ø (mm)
Sheath Ø (mm)

Gewiss-code DX43316
Conduits Ø (mm) 16
Sheath Ø (mm) 12
Ga
Gewiss-code DX43320
Conduits Ø (mm) 20
Sheath Ø (mm) 16
Ga
Gewiss-code DX43325
Conduits Ø (mm) 25
Sheath Ø (mm) 20
Ga
Gewiss-code DX43332
Conduits Ø (mm) 32
Sheath Ø (mm) 25
Ga
Gewiss-code DX43340
Conduits Ø (mm) 40
Sheath Ø (mm) 32
Ga
Gewiss-code DX43350
Conduits Ø (mm) 50
Sheath Ø (mm) 40
Ga
UITRUSTING EN OPMERKINGEN
LA SVOLTA conduit-conduit union - IP65
LA SVOLTA conduit-conduit union - IP65
Gewiss-code
Conduits Ø (mm)
Working length (mm)

Gewiss-code DX43516
Conduits Ø (mm) 16
Working length (mm) 110
Ga
Gewiss-code DX43520
Conduits Ø (mm) 20
Working length (mm) 132
Ga
Gewiss-code DX43525
Conduits Ø (mm) 25
Working length (mm) 209
Ga
Gewiss-code DX43532
Conduits Ø (mm) 32
Working length (mm) 301
Ga
Gewiss-code DX43540
Conduits Ø (mm) 40
Working length (mm) 302
Ga
Gewiss-code DX43550
Conduits Ø (mm) 50
Working length (mm) 311
Ga

SPEEDY-FLEX couplings - Grey RAL 7035

Watertight flexible couplings - IP66
Watertight flexible couplings - IP66
Gewiss-code
For external conduits (mm)
External Ø (mm)
Internal Ø (mm)
Length (mm)

Gewiss-code GW50201
For external conduits (mm) 16
External Ø (mm) 27
Internal Ø (mm) 13
Length (mm) 140
Ga
Gewiss-code GW50202
For external conduits (mm) 20
External Ø (mm) 31.5
Internal Ø (mm) 17
Length (mm) 160
Ga
Gewiss-code GW50203
For external conduits (mm) 25
External Ø (mm) 41
Internal Ø (mm) 21.5
Length (mm) 205
Ga
Gewiss-code GW50204
For external conduits (mm) 32
External Ø (mm) 55
Internal Ø (mm) 28
Length (mm) 290
Ga
Gewiss-code GW50205
For external conduits (mm) 40
External Ø (mm) 65
Internal Ø (mm) 35.5
Length (mm) 400
Ga
Gewiss-code GW50206
For external conduits (mm) 50
External Ø (mm) 72
Internal Ø (mm) 44.5
Length (mm) 515
Ga
UITRUSTING EN OPMERKINGEN
Protected flexible couplings - IP44
Protected flexible couplings - IP44
Gewiss-code
For external conduits (mm)
External Ø (mm)
Internal Ø (mm)
Length (mm)

Gewiss-code GW50207
For external conduits (mm) 16
External Ø (mm) 24
Internal Ø (mm) 13
Length (mm) 135
Ga
Gewiss-code GW50208
For external conduits (mm) 20
External Ø (mm) 30
Internal Ø (mm) 17
Length (mm) 160
Ga
Gewiss-code GW50209
For external conduits (mm) 25
External Ø (mm) 35
Internal Ø (mm) 21.5
Length (mm) 205
Ga
Gewiss-code GW50210
For external conduits (mm) 32
External Ø (mm) 45
Internal Ø (mm) 28
Length (mm) 280
Ga
Gewiss-code GW50211
For external conduits (mm) 40
External Ø (mm) 55
Internal Ø (mm) 35.5
Length (mm) 400
Ga
Gewiss-code GW50212
For external conduits (mm) 50
External Ø (mm) 65
Internal Ø (mm) 44.5
Length (mm) 515
Ga
UITRUSTING EN OPMERKINGEN

Accessories

UITRUSTING EN OPMERKINGEN

Rotating unions

Straight, revolving coupling device - Metric pitch - IP54
Straight, revolving coupling device - Metric pitch - IP54
Gewiss-code
Colour
Sheath Ø (mm)
ISO pitch

Gewiss-code DX54008
Colour Grey RAL 7035
Sheath Ø (mm) 8
ISO pitch M 12x1.5
Ga
Gewiss-code DX54010
Colour Grey RAL 7035
Sheath Ø (mm) 10
ISO pitch M 16x1.5
Ga
Gewiss-code DX54012
Colour Grey RAL 7035
Sheath Ø (mm) 12
ISO pitch M 16x1.5
Ga
Gewiss-code DX54016
Colour Grey RAL 7035
Sheath Ø (mm) 16
ISO pitch M 20x1.5
Ga
Gewiss-code DX54020
Colour Grey RAL 7035
Sheath Ø (mm) 20
ISO pitch M 25x1.5
Ga
Gewiss-code DX54022
Colour Grey RAL 7035
Sheath Ø (mm) 22
ISO pitch M 25x1.5
Ga
Gewiss-code DX54025
Colour Grey RAL 7035
Sheath Ø (mm) 25
ISO pitch M 32x1.5
Ga
Gewiss-code DX54028
Colour Grey RAL 7035
Sheath Ø (mm) 28
ISO pitch M 32x1.5
Ga
Gewiss-code DX54032
Colour Grey RAL 7035
Sheath Ø (mm) 32
ISO pitch M 40x1.5
Ga
Gewiss-code DX54040
Colour Grey RAL 7035
Sheath Ø (mm) 40
ISO pitch M 50x1.5
Ga
Gewiss-code DX54050
Colour Grey RAL 7035
Sheath Ø (mm) 50
ISO pitch M 63x1.5
Ga
Gewiss-code DX54108
Colour Black RAL 9005
Sheath Ø (mm) 8
ISO pitch M 12x1.5
Ga
Gewiss-code DX54110
Colour Black RAL 9005
Sheath Ø (mm) 10
ISO pitch M 16x1.5
Ga
Gewiss-code DX54112
Colour Black RAL 9005
Sheath Ø (mm) 12
ISO pitch M 16x1.5
Ga
Gewiss-code DX54116
Colour Black RAL 9005
Sheath Ø (mm) 16
ISO pitch M 20x1.5
Ga
Gewiss-code DX54120
Colour Black RAL 9005
Sheath Ø (mm) 20
ISO pitch M 25x1.5
Ga
Gewiss-code DX54122
Colour Black RAL 9005
Sheath Ø (mm) 22
ISO pitch M 25x1.5
Ga
Gewiss-code DX54125
Colour Black RAL 9005
Sheath Ø (mm) 25
ISO pitch M 32x1.5
Ga
Gewiss-code DX54128
Colour Black RAL 9005
Sheath Ø (mm) 28
ISO pitch M 32x1.5
Ga
Gewiss-code DX54132
Colour Black RAL 9005
Sheath Ø (mm) 32
ISO pitch M 40x1.5
Ga
Gewiss-code DX54140
Colour Black RAL 9005
Sheath Ø (mm) 40
ISO pitch M 50x1.5
Ga
Gewiss-code DX54150
Colour Black RAL 9005
Sheath Ø (mm) 50
ISO pitch M 63x1.5
Ga
UITRUSTING EN OPMERKINGEN
Straight, revolving coupling device - GAS pitch - IP54
Straight, revolving coupling device - GAS pitch - IP54
Gewiss-code
Colour
Sheath Ø (mm)
GAS pitch

Gewiss-code DX54208
Colour Grey RAL 7035
Sheath Ø (mm) 8
GAS pitch 1/4"
Ga
Gewiss-code DX54210
Colour Grey RAL 7035
Sheath Ø (mm) 10
GAS pitch 1/4"
Ga
Gewiss-code DX54212
Colour Grey RAL 7035
Sheath Ø (mm) 12
GAS pitch 3/8"
Ga
Gewiss-code DX54214
Colour Grey RAL 7035
Sheath Ø (mm) 14
GAS pitch 1/2"
Ga
Gewiss-code DX54216
Colour Grey RAL 7035
Sheath Ø (mm) 16
GAS pitch 1/2"
Ga
Gewiss-code DX54220
Colour Grey RAL 7035
Sheath Ø (mm) 20
GAS pitch 3/4"
Ga
Gewiss-code DX54222
Colour Grey RAL 7035
Sheath Ø (mm) 22
GAS pitch 3/4"
Ga
Gewiss-code DX54225
Colour Grey RAL 7035
Sheath Ø (mm) 25
GAS pitch 1"
Ga
Gewiss-code DX54228
Colour Grey RAL 7035
Sheath Ø (mm) 28
GAS pitch 1"
Ga
Gewiss-code DX54232
Colour Grey RAL 7035
Sheath Ø (mm) 32
GAS pitch 1 1/4"
Ga
Gewiss-code DX54235
Colour Grey RAL 7035
Sheath Ø (mm) 35
GAS pitch 1 1/4"
Ga
Gewiss-code DX54240
Colour Grey RAL 7035
Sheath Ø (mm) 40
GAS pitch 1 1/2"
Ga
Gewiss-code DX54250
Colour Grey RAL 7035
Sheath Ø (mm) 50
GAS pitch 2"
Ga
Gewiss-code DX54308
Colour Black RAL 9005
Sheath Ø (mm) 8
GAS pitch 1/4"
Ga
Gewiss-code DX54310
Colour Black RAL 9005
Sheath Ø (mm) 10
GAS pitch 1/4"
Ga
Gewiss-code DX54312
Colour Black RAL 9005
Sheath Ø (mm) 12
GAS pitch 3/8"
Ga
Gewiss-code DX54314
Colour Black RAL 9005
Sheath Ø (mm) 14
GAS pitch 1/2"
Ga
Gewiss-code DX54316
Colour Black RAL 9005
Sheath Ø (mm) 16
GAS pitch 1/2"
Ga
Gewiss-code DX54320
Colour Black RAL 9005
Sheath Ø (mm) 20
GAS pitch 3/4"
Ga
Gewiss-code DX54322
Colour Black RAL 9005
Sheath Ø (mm) 22
GAS pitch 3/4"
Ga
Gewiss-code DX54325
Colour Black RAL 9005
Sheath Ø (mm) 25
GAS pitch 1"
Ga
Gewiss-code DX54328
Colour Black RAL 9005
Sheath Ø (mm) 28
GAS pitch 1"
Ga
Gewiss-code DX54332
Colour Black RAL 9005
Sheath Ø (mm) 32
GAS pitch 1 1/4"
Ga
Gewiss-code DX54335
Colour Black RAL 9005
Sheath Ø (mm) 35
GAS pitch 1 1/4"
Ga
Gewiss-code DX54340
Colour Black RAL 9005
Sheath Ø (mm) 40
GAS pitch 1 1/2"
Ga
Gewiss-code DX54350
Colour Black RAL 9005
Sheath Ø (mm) 50
GAS pitch 2"
Ga
UITRUSTING EN OPMERKINGEN
Straight, revolving coupling device - PG pitch - IP54
Straight, revolving coupling device - PG pitch - IP54
Gewiss-code
Colour
Sheath Ø (mm)
PG pitch

Gewiss-code DX54408
Colour Grey RAL 7035
Sheath Ø (mm) 8
PG pitch 7
Ga
Gewiss-code DX54410
Colour Grey RAL 7035
Sheath Ø (mm) 10
PG pitch 7
Ga
Gewiss-code DX54411
Colour Grey RAL 7035
Sheath Ø (mm) 10
PG pitch 9
Ga
Gewiss-code DX54412
Colour Grey RAL 7035
Sheath Ø (mm) 12
PG pitch 11
Ga
Gewiss-code DX54413
Colour Grey RAL 7035
Sheath Ø (mm) 12
PG pitch 13.5
Ga
Gewiss-code DX54414
Colour Grey RAL 7035
Sheath Ø (mm) 14
PG pitch 13.5
Ga
Gewiss-code DX54416
Colour Grey RAL 7035
Sheath Ø (mm) 16
PG pitch 13.5
Ga
Gewiss-code DX54417
Colour Grey RAL 7035
Sheath Ø (mm) 16
PG pitch 16
Ga
Gewiss-code DX54420
Colour Grey RAL 7035
Sheath Ø (mm) 20
PG pitch 21
Ga
Gewiss-code DX54422
Colour Grey RAL 7035
Sheath Ø (mm) 22
PG pitch 21
Ga
Gewiss-code DX54425
Colour Grey RAL 7035
Sheath Ø (mm) 25
PG pitch 29
Ga
Gewiss-code DX54428
Colour Grey RAL 7035
Sheath Ø (mm) 28
PG pitch 29
Ga
Gewiss-code DX54432
Colour Grey RAL 7035
Sheath Ø (mm) 32
PG pitch 36
Ga
Gewiss-code DX54435
Colour Grey RAL 7035
Sheath Ø (mm) 35
PG pitch 36
Ga
Gewiss-code DX54508
Colour Black RAL 9005
Sheath Ø (mm) 8
PG pitch 7
Ga
Gewiss-code DX54510
Colour Black RAL 9005
Sheath Ø (mm) 10
PG pitch 7
Ga
Gewiss-code DX54511
Colour Black RAL 9005
Sheath Ø (mm) 10
PG pitch 9
Ga
Gewiss-code DX54512
Colour Black RAL 9005
Sheath Ø (mm) 12
PG pitch 11
Ga
Gewiss-code DX54513
Colour Black RAL 9005
Sheath Ø (mm) 12
PG pitch 13.5
Ga
Gewiss-code DX54514
Colour Black RAL 9005
Sheath Ø (mm) 14
PG pitch 13.5
Ga
Gewiss-code DX54516
Colour Black RAL 9005
Sheath Ø (mm) 16
PG pitch 13.5
Ga
Gewiss-code DX54517
Colour Black RAL 9005
Sheath Ø (mm) 16
PG pitch 16
Ga
Gewiss-code DX54520
Colour Black RAL 9005
Sheath Ø (mm) 20
PG pitch 21
Ga
Gewiss-code DX54522
Colour Black RAL 9005
Sheath Ø (mm) 22
PG pitch 21
Ga
Gewiss-code DX54525
Colour Black RAL 9005
Sheath Ø (mm) 25
PG pitch 29
Ga
Gewiss-code DX54528
Colour Black RAL 9005
Sheath Ø (mm) 28
PG pitch 29
Ga
Gewiss-code DX54532
Colour Black RAL 9005
Sheath Ø (mm) 32
PG pitch 36
Ga
Gewiss-code DX54535
Colour Black RAL 9005
Sheath Ø (mm) 35
PG pitch 36
Ga
UITRUSTING EN OPMERKINGEN

Fixed unions

Straight, fixed coupling device - Metric pitch - IP54
Straight, fixed coupling device - Metric pitch - IP54
Gewiss-code
Colour
Sheath Ø (mm)
ISO pitch

Gewiss-code DX56008
Colour Grey RAL 7035
Sheath Ø (mm) 8
ISO pitch M12x1
Ga
Gewiss-code DX56010
Colour Grey RAL 7035
Sheath Ø (mm) 10
ISO pitch M16x1.5
Ga
Gewiss-code DX56012
Colour Grey RAL 7035
Sheath Ø (mm) 12
ISO pitch M16x1.5
Ga
Gewiss-code DX56014
Colour Grey RAL 7035
Sheath Ø (mm) 14
ISO pitch M16x1.5
Ga
Gewiss-code DX56016
Colour Grey RAL 7035
Sheath Ø (mm) 16
ISO pitch M20x1.5
Ga
Gewiss-code DX56022
Colour Grey RAL 7035
Sheath Ø (mm) 22
ISO pitch M25x1.5
Ga
Gewiss-code DX56025
Colour Grey RAL 7035
Sheath Ø (mm) 25
ISO pitch M25x1.5
Ga
Gewiss-code DX56028
Colour Grey RAL 7035
Sheath Ø (mm) 28
ISO pitch M32x1.5
Ga
Gewiss-code DX56040
Colour Grey RAL 7035
Sheath Ø (mm) 40
ISO pitch M40x1.5
Ga
Gewiss-code DX56050
Colour Grey RAL 7035
Sheath Ø (mm) 50
ISO pitch M50x1.5
Ga
UITRUSTING EN OPMERKINGEN
Straight, fixed coupling device - GAS pitch - IP54
Straight, fixed coupling device - GAS pitch - IP54
Gewiss-code
Colour
Sheath Ø (mm)
GAS pitch

Gewiss-code DX56208
Colour Grey RAL 7035
Sheath Ø (mm) 8
GAS pitch 1/4"
Ga
Gewiss-code DX56210
Colour Grey RAL 7035
Sheath Ø (mm) 10
GAS pitch 1/4"
Ga
Gewiss-code DX56212
Colour Grey RAL 7035
Sheath Ø (mm) 12
GAS pitch 3/8"
Ga
Gewiss-code DX56214
Colour Grey RAL 7035
Sheath Ø (mm) 14
GAS pitch 1/2"
Ga
Gewiss-code DX56216
Colour Grey RAL 7035
Sheath Ø (mm) 16
GAS pitch 1/2"
Ga
Gewiss-code DX56222
Colour Grey RAL 7035
Sheath Ø (mm) 22
GAS pitch 3/4"
Ga
Gewiss-code DX56225
Colour Grey RAL 7035
Sheath Ø (mm) 25
GAS pitch 3/4"
Ga
Gewiss-code DX56228
Colour Grey RAL 7035
Sheath Ø (mm) 28
GAS pitch 1"
Ga
Gewiss-code DX56232
Colour Grey RAL 7035
Sheath Ø (mm) 32
GAS pitch 1 1/4"
Ga
Gewiss-code DX56235
Colour Grey RAL 7035
Sheath Ø (mm) 35
GAS pitch 1 1/4"
Ga
Gewiss-code DX56240
Colour Grey RAL 7035
Sheath Ø (mm) 40
GAS pitch 1 1/2"
Ga
Gewiss-code DX56250
Colour Grey RAL 7035
Sheath Ø (mm) 50
GAS pitch 2"
Ga
UITRUSTING EN OPMERKINGEN
Straight, fixed coupling device - PG pitch - IP54
Straight, fixed coupling device - PG pitch - IP54
Gewiss-code
Colour
Sheath Ø (mm)
PG pitch

Gewiss-code DX56408
Colour Grey RAL 7035
Sheath Ø (mm) 8
PG pitch 7
Ga
Gewiss-code DX56410
Colour Grey RAL 7035
Sheath Ø (mm) 10
PG pitch 7
Ga
Gewiss-code DX56411
Colour Grey RAL 7035
Sheath Ø (mm) 12
PG pitch 9
Ga
Gewiss-code DX56412
Colour Grey RAL 7035
Sheath Ø (mm) 12
PG pitch 11
Ga
Gewiss-code DX56413
Colour Grey RAL 7035
Sheath Ø (mm) 12
PG pitch 13.5
Ga
Gewiss-code DX56414
Colour Grey RAL 7035
Sheath Ø (mm) 14
PG pitch 13.5
Ga
Gewiss-code DX56415
Colour Grey RAL 7035
Sheath Ø (mm) 16
PG pitch 11
Ga
Gewiss-code DX56416
Colour Grey RAL 7035
Sheath Ø (mm) 16
PG pitch 13.5
Ga
Gewiss-code DX56417
Colour Grey RAL 7035
Sheath Ø (mm) 16
PG pitch 16
Ga
Gewiss-code DX56422
Colour Grey RAL 7035
Sheath Ø (mm) 22
PG pitch 16
Ga
Gewiss-code DX56423
Colour Grey RAL 7035
Sheath Ø (mm) 22
PG pitch 21
Ga
Gewiss-code DX56425
Colour Grey RAL 7035
Sheath Ø (mm) 25
PG pitch 21
Ga
Gewiss-code DX56428
Colour Grey RAL 7035
Sheath Ø (mm) 28
PG pitch 29
Ga
Gewiss-code DX56432
Colour Grey RAL 7035
Sheath Ø (mm) 32
PG pitch 36
Ga
Gewiss-code DX56435
Colour Grey RAL 7035
Sheath Ø (mm) 35
PG pitch 36
Ga
Gewiss-code DX56440
Colour Grey RAL 7035
Sheath Ø (mm) 40
PG pitch 42
Ga
Gewiss-code DX56450
Colour Grey RAL 7035
Sheath Ø (mm) 50
PG pitch 48
Ga
UITRUSTING EN OPMERKINGEN

Conduit-sheath unions

MORBIDX release conduit-sheath union - IP65
MORBIDX release conduit-sheath union - IP65
Gewiss-code
Conduits Ø (mm)
Sheath Ø (mm)

Gewiss-code DX43316
Conduits Ø (mm) 16
Sheath Ø (mm) 12
Ga
Gewiss-code DX43320
Conduits Ø (mm) 20
Sheath Ø (mm) 16
Ga
Gewiss-code DX43325
Conduits Ø (mm) 25
Sheath Ø (mm) 20
Ga
Gewiss-code DX43332
Conduits Ø (mm) 32
Sheath Ø (mm) 25
Ga
Gewiss-code DX43340
Conduits Ø (mm) 40
Sheath Ø (mm) 32
Ga
Gewiss-code DX43350
Conduits Ø (mm) 50
Sheath Ø (mm) 40
Ga
UITRUSTING EN OPMERKINGEN

Standard type

Standard cable ties in colourless polymer
Standard cable ties in colourless polymer
Gewiss-code
Dimensions LxH (mm)
Tensile stress (daN)
Terminal grip capacity Ø

Gewiss-code GW52231
Dimensions LxH (mm) 2.4x75
Tensile stress (daN) 8
Terminal grip capacity Ø 2 - 13 mm
Ga
Gewiss-code GW52232
Dimensions LxH (mm) 2.5x96
Tensile stress (daN) 8
Terminal grip capacity Ø 2 - 19 mm
Ga
Gewiss-code GW52233
Dimensions LxH (mm) 2.5x142
Tensile stress (daN) 8
Terminal grip capacity Ø 3 - 32 mm
Ga
Gewiss-code GW52234
Dimensions LxH (mm) 2.5x203
Tensile stress (daN) 8
Terminal grip capacity Ø 4 - 50 mm
Ga
Gewiss-code GW52235
Dimensions LxH (mm) 3.6x150
Tensile stress (daN) 18
Terminal grip capacity Ø 3 - 33 mm
Ga
Gewiss-code GW52236
Dimensions LxH (mm) 3.6x203
Tensile stress (daN) 18
Terminal grip capacity Ø 5 - 47 mm
Ga
Gewiss-code GW52237
Dimensions LxH (mm) 3.6x292
Tensile stress (daN) 18
Terminal grip capacity Ø 7 - 75 mm
Ga
Gewiss-code GW52238
Dimensions LxH (mm) 4.8x190
Tensile stress (daN) 18
Terminal grip capacity Ø 4 - 45 mm
Ga
Gewiss-code GW52239
Dimensions LxH (mm) 4.8x280
Tensile stress (daN) 22
Terminal grip capacity Ø 7 - 70 mm
Ga
Gewiss-code GW52240
Dimensions LxH (mm) 4.8x368
Tensile stress (daN) 22
Terminal grip capacity Ø 7 - 96 mm
Ga
Gewiss-code GW52241
Dimensions LxH (mm) 7.6x380
Tensile stress (daN) 55
Terminal grip capacity Ø 8 - 96 mm
Ga
Gewiss-code GW52242
Dimensions LxH (mm) 9.0x610
Tensile stress (daN) 80
Terminal grip capacity Ø 11 - 162 mm
Ga
Gewiss-code GW52243
Dimensions LxH (mm) 9.0x914
Tensile stress (daN) 80
Terminal grip capacity Ø 12 - 253 mm
Ga
UITRUSTING EN OPMERKINGEN

Heavy-duty

Heavy duty wiring ties - black polymer
Heavy duty wiring ties - black polymer
Gewiss-code
Dimensions LxH (mm)
Tensile stress (daN)
Terminal grip capacity Ø

Gewiss-code GW52251
Dimensions LxH (mm) 2.4x75
Tensile stress (daN) 8
Terminal grip capacity Ø 2 - 13 mm
Ga
Gewiss-code GW52252
Dimensions LxH (mm) 2.5x96
Tensile stress (daN) 8
Terminal grip capacity Ø 2 - 19 mm
Ga
Gewiss-code GW52253
Dimensions LxH (mm) 2.5x142
Tensile stress (daN) 8
Terminal grip capacity Ø 3 - 32 mm
Ga
Gewiss-code GW52254
Dimensions LxH (mm) 2.5x203
Tensile stress (daN) 8
Terminal grip capacity Ø 4 - 50 mm
Ga
Gewiss-code GW52255
Dimensions LxH (mm) 3.6x150
Tensile stress (daN) 18
Terminal grip capacity Ø 3 - 33 mm
Ga
Gewiss-code GW52256
Dimensions LxH (mm) 3.6x203
Tensile stress (daN) 18
Terminal grip capacity Ø 5 - 47 mm
Ga
Gewiss-code GW52257
Dimensions LxH (mm) 3.6x292
Tensile stress (daN) 18
Terminal grip capacity Ø 7 - 75 mm
Ga
Gewiss-code GW52258
Dimensions LxH (mm) 4.8x190
Tensile stress (daN) 18
Terminal grip capacity Ø 4 - 45 mm
Ga
Gewiss-code GW52259
Dimensions LxH (mm) 4.8x280
Tensile stress (daN) 22
Terminal grip capacity Ø 7 - 70 mm
Ga
Gewiss-code GW52260
Dimensions LxH (mm) 4.8x368
Tensile stress (daN) 22
Terminal grip capacity Ø 7 - 96 mm
Ga
Gewiss-code GW52261
Dimensions LxH (mm) 7.6x380
Tensile stress (daN) 55
Terminal grip capacity Ø 8 - 96 mm
Ga
Gewiss-code GW52262
Dimensions LxH (mm) 9.0x610
Tensile stress (daN) 80
Terminal grip capacity Ø 11 - 162 mm
Ga
Gewiss-code GW52263
Dimensions LxH (mm) 9.0x914
Tensile stress (daN) 80
Terminal grip capacity Ø 12 - 253 mm
Ga
UITRUSTING EN OPMERKINGEN

Re-openable

With eyelet

With plate

UITRUSTING EN OPMERKINGEN

Complementary items

UITRUSTING EN OPMERKINGEN

L.T.R. ties

Outdoor black ties in L.T.R. polyamide 12
Outdoor black ties in L.T.R. polyamide 12
Gewiss-code
Dimensions LxH (mm)
Number of heads
Tensile stress (daN)
Terminal grip capacity Ø

Gewiss-code GW52201
Dimensions LxH (mm) 6x115
Number of heads 1
Tensile stress (daN) 24.5
Terminal grip capacity Ø 5 - 25 mm
Ga
Gewiss-code GW52202
Dimensions LxH (mm) 6x180
Number of heads 1
Tensile stress (daN) 24.5
Terminal grip capacity Ø 9 - 45 mm
Ga
Gewiss-code GW52203
Dimensions LxH (mm) 6x290
Number of heads 1
Tensile stress (daN) 24.5
Terminal grip capacity Ø 20 - 78 mm
Ga
Gewiss-code GW52204
Dimensions LxH (mm) 9x180
Number of heads 1
Tensile stress (daN) 36
Terminal grip capacity Ø 10 - 40 mm
Ga
Gewiss-code GW52205
Dimensions LxH (mm) 9x265
Number of heads 2
Tensile stress (daN) 50
Terminal grip capacity Ø 26 - 60 mm
Ga
Gewiss-code GW52206
Dimensions LxH (mm) 9x360
Number of heads 2
Tensile stress (daN) 50
Terminal grip capacity Ø 26 - 93 mm
Ga
Gewiss-code GW52207
Dimensions LxH (mm) 9x510
Number of heads 2
Tensile stress (daN) 53
Terminal grip capacity Ø 70 - 140 mm
Ga
Gewiss-code GW52208
Dimensions LxH (mm) 9x760
Number of heads 2
Tensile stress (daN) 53
Terminal grip capacity Ø 70 - 220 mm
Ga
UITRUSTING EN OPMERKINGEN

Complementary items

UITRUSTING EN OPMERKINGEN

Trailing terminals blocks

Mobile terminal blocks with modular busbars - 450V - T 85°C - Transparent - IP20
Mobile terminal blocks with modular busbars - 450V - T 85°C - Transparent - IP20
Gewiss-code
Type of screw
Max. section flex. cables
Min. section flex. cables
No. poles per bar

Gewiss-code GW44661
Type of screw Slotted
Max. section flex. cables 2.5 mm²
Min. section flex. cables 1 mm²
No. poles per bar 10
Ga
Gewiss-code GW44665
Type of screw Slotted
Max. section flex. cables 4 mm²
Min. section flex. cables 1.5 mm²
No. poles per bar 10
Ga
Gewiss-code GW44662
Type of screw Slotted
Max. section flex. cables 6 mm²
Min. section flex. cables 2.5 mm²
No. poles per bar 10
Ga
Gewiss-code GW44663
Type of screw Slotted
Max. section flex. cables 10 mm²
Min. section flex. cables 4 mm²
No. poles per bar 10
Ga
Gewiss-code GW44664
Type of screw Slotted
Max. section flex. cables 16 mm²
Min. section flex. cables 6 mm²
No. poles per bar 5
Ga
Gewiss-code GW44666
Type of screw Socket head 5mm
Max. section flex. cables 25 mm²
Min. section flex. cables 10 mm²
No. poles per bar 1
Ga
Gewiss-code GW44667
Type of screw Socket head 5mm
Max. section flex. cables 35 mm²
Min. section flex. cables 16 mm²
No. poles per bar 1
Ga
UITRUSTING EN OPMERKINGEN

Modular terminal blocks

Polymer 12 pole modular terminal blocks with brass terminals - 450V - T 85°C - Black
Polymer 12 pole modular terminal blocks with brass terminals - 450V - T 85°C - Black
Gewiss-code
Max. section flex. cables
Min. section flex. cables
hole Ø
Max load
Outer dim. LxHxD (mm)
Fixing

Gewiss-code GW44601
Max. section flex. cables 2.5 mm²
Min. section flex. cables 0.75 mm²
hole Ø 2.9 mm
Max load 24 A
Outer dim. LxHxD (mm) 95x15x16
Fixing With screw
Ga
Gewiss-code GW44602
Max. section flex. cables 4 mm²
Min. section flex. cables 1.5 mm²
hole Ø 3.4 mm
Max load 32 A
Outer dim. LxHxD (mm) 117x17x20
Fixing With screw
Ga
Gewiss-code GW44603
Max. section flex. cables 10 mm²
Min. section flex. cables 4 mm²
hole Ø 4.4 mm
Max load 57 A
Outer dim. LxHxD (mm) 141x20x23
Fixing With screw
Ga
Gewiss-code GW44604
Max. section flex. cables 16 mm²
Min. section flex. cables 6 mm²
hole Ø 5.8 mm
Max load 76 A
Outer dim. LxHxD (mm) 172x25x32
Fixing With screw
Ga
Gewiss-code GW44605
Max. section flex. cables 25 mm²
Min. section flex. cables 10 mm²
hole Ø 7.4 mm
Max load 101 A
Outer dim. LxHxD (mm) 210x34x38
Fixing With screw
Ga

Press-on fixing

Screw-on fixing
