FRONT COVERS AND DIN FRAMES FOR DECORATIVE ENCLOSURES - TONER BLACK - 12+1 MODULES

Kód: GW41229TN

Řada: 40 CDI Range
Flush-mounting distribution boards and enclosures

The widest offer of flush-mounting distribution boards and enclosures currently available on the market. Seven families designed to offer advanced solutions in the residential and commercial sector, also available in halogen-free material. Versions from 2 to 72 modules, degree of protection from IP40 to IP55 and special versions for plasterboard. The range includes also two Multimedia Enclosures: Full Version (54 modules) and Compact Version (36 modules).

Technické informace

Informace

Stáhnout

Certifikáty

No. of modules EN 50022 12+1

Colour Black

Front dim. LxHxD (mm) 330x218x25

Corresponding back plate GW40674

Dispersible power (W) 24

Ware Number 85381000

User guide

Technical characteristics - IT

Technical characteristics - EN

Technical characteristics - DE

Technical characteristics - ES

Přejít do oblasti pro stahování Přejít do oblasti pro stahování

Display the certificate

CE marking

VYBAVENÍ A POZNÁMKY

ACCESSORIES SUPPLIED: 6.5M module-covering profiles co-ordinated with the colour of the enclosure front (for 4, 8 and 12-module enclosures - 1 profile; for 24-module enclosures - 2 profiles; for 36-module enclosures- 3 profiles), service labels.
NOTES: dispersible power calculated according to IEC 60670-24.
CHARACTERISTICS: Module-covering profiles can be divided into 1/2 module elements, using scissors. Thermo-pressure with ball equal to 70°C.
IP40 guaranteed even with open door, in the case of wall-embedded installation using devices of at least IP40 and the module-covering profiles supplied.
Front of the enclosure and DIN rail frame fully compatible with the bottom of the previous decorative flush mounting enclosures 40CDi Range.
