Installation Flush-mounting enclosures 24 SC Range- Flush-mounting, surface-mounting and underfloor boxes

24 SC Range
Flush-mounting, surface-mounting and underfloor boxes

Wide range of surface-mounting and flush-mounting boxes for domestic ranges with high mechanical robustness and accessories supplied: dividers, junction elements, mortarguard shield etc.. Completing the range, the distribution outlet boxes for floor-mounting installations can be personalised in terms of capacity, external design finish, and internal fittings (they take both System range components and DIN rail devices).

See all product
Benefits
Boxes for underfloor applications
Boxes for brick walls
Boxes for surface-mounting domestic range plates
Boxes for underfloor applications
Boxes for underfloor applications
The range of underfloor boxes meets the demands for safety, connectivity and energy usage. 10-20 or 16-32 System module versions, with walkable cover (empty or stainless finish). Also available metal casing for installation in poured cement floors.
Boxes for brick walls
Boxes for brick walls
The BIG BOX robust, high-capacity boxes are ideal for traditional and smart home applications. They differ to conventional products due to their greater internal space and the large number of accessories available (mortar guards, separators, joining elements, etc.).
Boxes for surface-mounting domestic range plates
Boxes for surface-mounting domestic range plates
Developed with an aesthetic line that adapts to the GEWISS domestic series plate design, the wall boxes for the ChoruSmart, System and Playbus ranges make quality installations possible even in environments where concealed installation is not possible.

The products of this series

Navigate by catalogue
All filters
64 products
Grid
List

Underfloor outlet boxes - With supports positioned horizontally

Underfloor outlet boxes - With supports positioned horizontally

Category
Underfloor outlet boxes with hollow lid - Glow wire test 850° C

Change category

Change category

Underfloor outlet boxes with hollow lid - Glow wire test 850° C
Underfloor outlet boxes with stainless steel lid - Glow wire test 850° C
Cod Gewiss
Internal modularity
No. of supports
Outer dim. LxHxD (mm)
UNDERFLOOR OUTLET BOX - WITH HOLLOW COVER - 10 MODULES SYSTEM
GW24601
10 SYSTEM modules
2 supports with 5 System mod.
212x98x320
UNDERFLOOR OUTLET BOX - WITH HOLLOW COVER - 20 MODULES SYSTEM
GW24602
20 SYSTEM modules
4 supports with 5 System mod.
364x98x320
UNDERFLOOR OUTLET BOX - WITH HOLLOW COVER - 10 MODULES SYSTEM
GW24601
UNDERFLOOR OUTLET BOX - WITH HOLLOW COVER - 10 MODULES SYSTEM
Show
UNDERFLOOR OUTLET BOX - WITH HOLLOW COVER - 20 MODULES SYSTEM
GW24602
UNDERFLOOR OUTLET BOX - WITH HOLLOW COVER - 20 MODULES SYSTEM
Show
Cod Gewiss
Internal modularity
No. of supports
Outer dim. LxHxD (mm)
UNDERFLOOR OUTLET BOX - WITH STAINLESS STEEL COVER - 10 MODULES SYSTEM
GW24611
10 SYSTEM modules
2 supports with 5 System mod.
212x98x320
UNDERFLOOR OUTLET BOX - WITH STAINLESS STEEL COVER - 20 MODULES SYSTEM
GW24612
20 SYSTEM modules
4 supports with 5 System mod.
364x98x320
UNDERFLOOR OUTLET BOX - WITH STAINLESS STEEL COVER - 10 MODULES SYSTEM
GW24611
UNDERFLOOR OUTLET BOX - WITH STAINLESS STEEL COVER - 10 MODULES SYSTEM
Show
UNDERFLOOR OUTLET BOX - WITH STAINLESS STEEL COVER - 20 MODULES SYSTEM
GW24612
UNDERFLOOR OUTLET BOX - WITH STAINLESS STEEL COVER - 20 MODULES SYSTEM
Show

Underfloor outlet boxes - With supports positioned horizontally

Category
Underfloor outlet boxes with hollow lid - Glow wire test 850° C

Change category

Change category

Underfloor outlet boxes with hollow lid - Glow wire test 850° C
Underfloor outlet boxes with stainless steel lid - Glow wire test 850° C
Cod Gewiss
Internal modularity
No. of bases
No. of supports
Outer dim. LxHxD (mm)
UNDERFLOOR OUTLET BOX - HOLLOW COVER - 16 MODULES SYSTEM
GW24606
16 SYSTEM modules
1 base
8 supports with 2 System mod.
212x98x320
UNDERFLOOR OUTLET BOX - HOLLOW COVER - 32 MODULES SYSTEM
GW24607
32 SYSTEM modules
2 bases
16 supports with 2 System mod.
364x98x320
UNDERFLOOR OUTLET BOX - HOLLOW COVER - 16 MODULES SYSTEM
GW24606
UNDERFLOOR OUTLET BOX - HOLLOW COVER - 16 MODULES SYSTEM
Show
UNDERFLOOR OUTLET BOX - HOLLOW COVER - 32 MODULES SYSTEM
GW24607
UNDERFLOOR OUTLET BOX - HOLLOW COVER - 32 MODULES SYSTEM
Show
Cod Gewiss
Internal modularity
No. of bases
No. of supports
Outer dim. LxHxD (mm)
UNDERFLOOR OUTLET BOX - INOX COVER - 16 MODULES SYSTEM
GW24616
16 SYSTEM modules
1 base
8 supports with 2 System mod.
212x98x320
UNDERFLOOR OUTLET BOX - INOX COVER - 32 MODULES SYSTEM
GW24617
32 SYSTEM modules
2 bases
16 supports with 2 System mod.
364x98x320
UNDERFLOOR OUTLET BOX - INOX COVER - 16 MODULES SYSTEM
GW24616
UNDERFLOOR OUTLET BOX - INOX COVER - 16 MODULES SYSTEM
Show
UNDERFLOOR OUTLET BOX - INOX COVER - 32 MODULES SYSTEM
GW24617
UNDERFLOOR OUTLET BOX - INOX COVER - 32 MODULES SYSTEM
Show

Accessories

Category
Metal casing

Change category

Change category

Metal casing
Kit for installation of devices on DIN rail
Cod Gewiss
Suitable for outlet boxes
METAL CASING - FOR OUTLET BOX 10 MODULES
GW24621
GW24601, GW24611, GW24606, GW24616
METAL CASING - FOR OUTLET BOX 20 MODULES
GW24622
GW24602, GW24612, GW24607, GW24617
METAL CASING - FOR OUTLET BOX 10 MODULES
GW24621
METAL CASING - FOR OUTLET BOX 10 MODULES
Show
METAL CASING - FOR OUTLET BOX 20 MODULES
GW24622
METAL CASING - FOR OUTLET BOX 20 MODULES
Show
Cod Gewiss
Suitable for outlet boxes
KIT FOR INSTALLATION OF DEVICES ON DIN RAIL - FOR UNDERFLOOR OUTLET BOX
GW24633
GW24601, GW24611, GW24602, GW24612
KIT FOR INSTALLATION OF DEVICES ON DIN RAIL - FOR UNDERFLOOR OUTLET BOX
GW24633
KIT FOR INSTALLATION OF DEVICES ON DIN RAIL - FOR UNDERFLOOR OUTLET BOX
Show
You saw 11 products on 64
Show others
