ENERGY METER - MID BUS - THREE PHASE - DIGITAL - DIRECT 80A - 4 MODULES

Code: GWD6804
Range: 90 AM Range
Modular accessories
The 90 AM range, in addition to auxiliaries common for the all circuit breakers, comprises many modular accessories for the protection, command, programming, measurement and signalling in electrical systems.

Technical Info

Information
Download
Software
Certificates
Type MID Yes
Integrated Modbus Yes
Accuracy 1 (active energy) 2 (reactive energy)
Connection Direct (I max=80 A)
Rated voltage (V) 400 ac
No. of modules EN 50022 4
Ware Number 90283019

Technical characteristics - IT

Technical characteristics - DE

Technical characteristics - EN

Technical characteristics - ES

Disposal

User guide

CENTRAL

Quotation and Thermal test of modular enclosures

Show more

ENERGYpro

Boards for building sites, campings-piers and distribution

Show more

PBT-Q

Low voltage systems and boards

Show more

PRICE

Estimation of electrical systems

Show more

CADpro

Advanced design of electrical systems

Show more

PROJEX

Low voltage system design

Show more

CE marking

EQUIPMENT AND NOTES
APPLICATION: they allow the measurement and visualisation on the display (No. digits: 7 units + 2 decimals) of the active and reactive energy values (exported and imported), instantaneous
active and reactive power values (exported and imported), apparent power, voltage, current, power factor, frequency, THD voltage and THD current.
If the GWD6807 and GWD6809 energy meters are used with the KNX GW90876 interface, the measured values can be sent by KNX BUS network.
If the GWD6807 and GWD6809 energy meters are used with the MODBUS GWD6820 interface, the measured values can be sent by Modbus RS485 network.
If the GWD6801 and GWD6802 energy meters are used with the LAN-TCP/IP GWD6821 interface, the measured values can be sent by TCP/IP network.
CHARACTERISTICS: the meters have two impulse outputs for remote energy consumption control.
