Installation Wall-mounting enclosures 42 RV Range-Surface and flush-mounting watertight emergency enclosures
All media

42 RV Range
Surface and flush-mounting watertight emergency enclosures

IP55 watertight enclosures, Red RAL 3000, available in 5 versions: with backlit push button; can be equipped with 22 mm dia. stop button or with rail coupling, the latter being available in Grey RAL 7035. The best seller is the GW42201, equipped with 1 NO contact and 1 NC contact and expandable up to 4 contacts, supplied with 1 long automatically operated push-button when glass is broken or short button for manual operation.

See all product
Benefits
Functionality and flexibility in a single item
Maximum security
Enclosures for emergency systems
Functionality and flexibility in a single item
Functionality and flexibility in a single item
The GW42201 enclosure can be fitted with a short or long push button for voluntary movement or intrinsically safe operation, and has a back panel flange that expands the number of contacts installable up to four, thus increasing the configurable solutions.
Maximum security
Maximum security
All the enclosures have a high IP55 protection rating and thanks to the emergency hammer (available as accessory), breakable panel and halogen-free materials, they are suitable for use even in areas open to the public.
Enclosures for emergency systems
Enclosures for emergency systems
The GW42201 emergency-system enclosure is the ideal product for handling emergency systems. It can be fitted with up to four NO and NC contacts, and it also offers the possibility of signalling emergency circuit integrity, thanks to the green LED.

The products of this series

Navigate by catalogue
All filters
33 products
Grid
List

42 RV - Watertight enclosures for emergency manoeuvres - IP55

Equipment with illuminable push-button

Category
Watertight for emergency systems with 2 contacts 1NA+1NC expandable up to 4

Change category

Change category

Watertight for emergency systems with 2 contacts 1NA+1NC expandable up to 4
Cod Gewiss
Outer dim. LxHxD (mm)
Colour
No. of contacts that can be installed
WATERTIGHT ENCLOSURE FOR EMERGENCY SYSTEM WITH ILLUMINATED PUSH-BUTTON FOR LOCALISATION AND TWO CONTACTS
GW42201
120x120x50
Red RAL 3000
4
WATERTIGHT ENCLOSURE FOR EMERGENCY SYSTEM WITH ILLUMINATED PUSH-BUTTON FOR LOCALISATION AND TWO CONTACTS
GW42201
WATERTIGHT ENCLOSURE FOR EMERGENCY SYSTEM WITH ILLUMINATED PUSH-BUTTON FOR LOCALISATION AND TWO CONTACTS
Show

Fitted with hole Ø 22 mm

Category
Watertight enclosure for emergency systems fitted with hole Ø 22mm

Change category

Change category

Watertight enclosure for emergency systems fitted with hole Ø 22mm
Cod Gewiss
Outer dim. LxHxD (mm)
Colour
WATERTIGHT ENCLOSURE FOR EMERGENCY SYSTEM - FITTED WITH HOLE Ø 22MM
GW42204
108x180x100
Red RAL 3000
WATERTIGHT ENCLOSURE FOR EMERGENCY SYSTEM - FITTED WITH HOLE Ø 22MM
GW42204
WATERTIGHT ENCLOSURE FOR EMERGENCY SYSTEM - FITTED WITH HOLE Ø 22MM
Show

With DIN rail

Category
Watertight enclosures for emergency use and special applications

Change category

Change category

Watertight enclosures for emergency use and special applications
Cod Gewiss
Colour
No. of modules EN 50022
Outer dim. LxHxD (mm)
Dispersible power (W)
WATERTIGHT ENCLOSURE FOR EMERGENCY SYSTEM WITH DIN RAIL - 4 MODULES EN50022 - RED RAL 3000
GW42206
Red RAL 3000
4
108x180x100
12
WATERTIGHT ENCLOSURE FOR EMERGENCY SYSTEM WITH DIN RAIL - 8 MODULES EN50022 - RED RAL 3000
GW42202
Red RAL 3000
8
180x180x100
18
WATERTIGHT ENCLOSURE FOR EMERGENCY SYSTEM WITH DIN RAIL - 4 MODULES EN50022 - GREY RAL 7035
GW42207
Grey RAL 7035
4
108x180x100
12
WATERTIGHT ENCLOSURE FOR EMERGENCY SYSTEM WITH DIN RAIL - 8 MODULES EN50022 - GREY RAL 7035
GW42208
Grey RAL 7035
8
180x180x100
18
WATERTIGHT ENCLOSURE FOR EMERGENCY SYSTEM WITH DIN RAIL - 4 MODULES EN50022 - RED RAL 3000
GW42206
WATERTIGHT ENCLOSURE FOR EMERGENCY SYSTEM WITH DIN RAIL - 4 MODULES EN50022 - RED RAL 3000
Show
WATERTIGHT ENCLOSURE FOR EMERGENCY SYSTEM WITH DIN RAIL - 8 MODULES EN50022 - RED RAL 3000
GW42202
WATERTIGHT ENCLOSURE FOR EMERGENCY SYSTEM WITH DIN RAIL - 8 MODULES EN50022 - RED RAL 3000
Show
WATERTIGHT ENCLOSURE FOR EMERGENCY SYSTEM WITH DIN RAIL - 4 MODULES EN50022 - GREY RAL 7035
GW42207
WATERTIGHT ENCLOSURE FOR EMERGENCY SYSTEM WITH DIN RAIL - 4 MODULES EN50022 - GREY RAL 7035
Show
WATERTIGHT ENCLOSURE FOR EMERGENCY SYSTEM WITH DIN RAIL - 8 MODULES EN50022 - GREY RAL 7035
GW42208
WATERTIGHT ENCLOSURE FOR EMERGENCY SYSTEM WITH DIN RAIL - 8 MODULES EN50022 - GREY RAL 7035
Show

With back-mounting plate

Category
Watertight enclosure for emergency use and special applications

Change category

Change category

Watertight enclosure for emergency use and special applications
Cod Gewiss
Outer dim. LxHxD (mm)
Colour
WATERTIGHT ENCLOSURE FOR EMERGENCY SYSTEM - WITH GALVANISED METAL BACK MOUNTING PLATE
GW42203
180x180x100
Red RAL 3000
WATERTIGHT ENCLOSURE FOR EMERGENCY SYSTEM - WITH GALVANISED METAL BACK MOUNTING PLATE
GW42203
WATERTIGHT ENCLOSURE FOR EMERGENCY SYSTEM - WITH GALVANISED METAL BACK MOUNTING PLATE
Show

Flush-mounting enclosure with DIN rail

Category
Watertight, flush-mounting for emergencies and special applications with DIN rail

Change category

Change category

Watertight, flush-mounting for emergencies and special applications with DIN rail
Cod Gewiss
No. of modules EN 50022
Outer dim. LxHxD (mm)
Dispersible power (W)
Colour
WATERTIGHT FLUSH-MOUNTING ENCLOSURE FOR EMERCENGY - 4 MODULES - GUIDA EN50022 - RED RAL 3000
GW42231
4
145x200x70
12
Red RAL 3000
WATERTIGHT FLUSH-MOUNTING ENCLOSURE FOR EMERCENGY - 4 MODULES - GUIDA EN50022 - GREY RAL 7035
GW42232
4
145x200x70
12
Grey RAL 7035
WATERTIGHT FLUSH-MOUNTING ENCLOSURE FOR EMERCENGY - 4 MODULES - GUIDA EN50022 - RED RAL 3000
GW42231
WATERTIGHT FLUSH-MOUNTING ENCLOSURE FOR EMERCENGY - 4 MODULES - GUIDA EN50022 - RED RAL 3000
Show
WATERTIGHT FLUSH-MOUNTING ENCLOSURE FOR EMERCENGY - 4 MODULES - GUIDA EN50022 - GREY RAL 7035
GW42232
WATERTIGHT FLUSH-MOUNTING ENCLOSURE FOR EMERCENGY - 4 MODULES - GUIDA EN50022 - GREY RAL 7035
Show
You saw 9 products on 33
Show others
