PROTECTED ENCLOSURE COMPLETE WITH SYSTEM DEVICES - WITH ONE-WAY SWITCH 1P 16 AX - IP40 - GREY RAL 7035
Code:
GW27801
Range: 27 COMBI Range
Wall-mounting enclosures and modular components
Wall-mounting enclosures and modular components
A complete, versatile system of modular enclosures, perfectly integrated in the SYSTEM domestic range capable to meet the high protection installation requirements of domestic, commercial and industrial sectors. The 27 COMBI range is available both in the IP40 version and in watertight versions with IP55 and IP65 degree of protection, recommended for all outdoor applications which are subjected to extreme atmospheric conditions.
IP40
650 °C
70 °C
Technical Info
Information
Download
Software
Certificates
Description
One-way switch 1P - 16AX
Voltage
250 V ac
Colour
Grey RAL 7035
No. knockout holes Ø23
3 on sides / 1 on the bottom
N. holes Ø 23 with cable gland
1
Type of knockout holes
Removable with tool
IP degree
IP40
Insulation class
II
Lid screws
Corrosion-resistant steel
Torque screws tightening
0.8 Newton/meter
Outer dim. LxHxD (mm)
66x82x55
Glow Wire Test
650 °C
Thermo-pressure with ball
70 °C
Standard
EN 60669-1
Installation temperature
-25 +60 °C
Electrocod
0130
Ware Number
85371098
EQUIPMENT AND NOTES
CHARACTERISTICS: Knockout holes removable with tool. Enclosures are customized for fixing the earth terminal GW26407. Complete insulation can be obtained by using the screwcaps GW44622. GW27801, GW27802, GW27803, GW27804, rated power of 230V LED lamps: 200W.
ACCESSORIES SUPPLIED: quick entry cable gland for cables with Ø from 4 to 14 mm and conduits Ø 16 and 20 mm.
ACCESSORIES SUPPLIED: quick entry cable gland for cables with Ø from 4 to 14 mm and conduits Ø 16 and 20 mm.
