PROTECTED ENCLOSURE FOR SYSTEM DEVICES - HORIZONTAL MULTIPLE - 8 GANG - MODULE 4x2 - RAL 7035 GREY - IP40

Code: GW27006

Range: 27 COMBI Range
Wall-mounting enclosures and modular components

A complete, versatile system of modular enclosures, perfectly integrated in the SYSTEM domestic range capable to meet the high protection installation requirements of domestic, commercial and industrial sectors. The 27 COMBI range is available both in the IP40 version and in watertight versions with IP55 and IP65 degree of protection, recommended for all outdoor applications which are subjected to extreme atmospheric conditions.

IP40

IK07

650 °C

70 °C

Technical Info

Information

Download

Software

Certificates

Description 8 modules

Colour Grey RAL 7035

No. knockout holes Ø23 10 on sides / 2 on the bottom

Type of knockout holes Removable with tool

IP degree IP40

Insulation class II

Mechanical resistance IK07

Configuration Module 4 x 2

Compartment pre-arrangement 2

Characteristics Halogen free

Lid screws Corrosion-resistant steel

Torque screws tightening 0.8 Newton/meter

Outer dim. LxHxD (mm) 231x82x55

Glow Wire Test 650 °C

Thermo-pressure with ball 70 °C

Standard EN 60670-1

Installation temperature -25 +60 °C

Electrocod 0212

Ware Number 85381000

Product Data Sheet

BIM

DXF drawing

Technical characteristics - EN

Technical characteristics - IT

Technical characteristics - ES

Go to download area Go to download area

REVIT Plugin

Plugin with GEWISS products for the design software REVIT®

PRICE

Estimation of electrical systems

AUTOCAD Plugin

Plugin with GEWISS products for the software AUTOCAD®

CADpro

Advanced design of electrical systems

Go to software area Go to software area

Reach Declaration

CE marking

Display the certificate

EQUIPMENT AND NOTES

CHARACTERISTICS: customized to be divided into compartments using the special functional dividers. Knockout holes removable with tool. Enclosures are customized for fixing the earth terminal GW26407. Complete insulation can be obtained by using the screwcaps GW44622.
ACCESSORIES SUPPLIED: quick entry cable gland for cables with Ø from 4 to 14 mm and conduits Ø 16 and 20 mm.
