ONE-WAY SWITCH 1P 250V ac - 10AX - NEUTRAL - 1/2 MODULE - GLOSSY WHITE - CHORUSMART
Code:
GW10021
Range: CHORUSMART - Domestic range
Glossy white modular devices
Glossy white modular devices
The ChoruSmart modular devices allow you to create infinite combinations of devices and plates, thanks to a complete range that covers all design, functional and installation needs.
Colours and finishes: glossy white, bright and versatile.
Unlimited functions in compact spaces: the ChoruSmart range consists of button keys with ½, 1 and 2 rocker modules, to optimise space according to needs, and axial buttons in the EVO or SMART version, to meet the latest requirements.
Front coupling: front coupling allows the components to be assembled and released quickly and easily, with no need to remove the support, which is the same for all plates and boxes.
Colours and finishes: glossy white, bright and versatile.
Unlimited functions in compact spaces: the ChoruSmart range consists of button keys with ½, 1 and 2 rocker modules, to optimise space according to needs, and axial buttons in the EVO or SMART version, to meet the latest requirements.
Front coupling: front coupling allows the components to be assembled and released quickly and easily, with no need to remove the support, which is the same for all plates and boxes.
125 °C
850 °C
Technical Info
Information
Download
Software
Certificates
Category
One-way switch
Button key
Neutral
Colour
Glossy white
Description
1P - 10AX
Voltage
250 V ac
Standard
EN 60669-1
Resistance at test voltage
2000 V at 50 Hz for 1 minute
Rated power of 230V LED lamps
100 W
Insulation resistance
> 5 MOhm
Wiring terminals
With screw
Prolonged operation switch (no.of position changes)
40.000 at In 250 V ac cosφ=0,6
Thermo-pressure with ball
125 °C
Glow Wire Test
850 °C
Terminal grip on cable traction
> 50 N
Terminal tightening capacity
stranded cables (mm²) min. 0,75 - max. 2x4
stranded cables (mm²) min. 0,75 - max. 2x4
Terminal tightening capacity
solid cables (mm²) min. 0,5 - max. 2x2,5
solid cables (mm²) min. 0,5 - max. 2x2,5
No. modules
1/2
Material
Technopolymer
Electrocod
0130
Ware Number
85365080
EQUIPMENT AND NOTES
CHARACTERISTICS: the illuminable articles use LED signalling units, not included.
