FIXED INTERLOCKED HORIZONTAL SOCKET-OUTLET - WITH BOTTOM - WITHOUT FUSE-HOLDER BASE - 2P+E 16A 380-415V - 50/60HZ 9H - IP44
Code:
GW66007
Range: IB Range
Interlocked socket-outlets IEC 309 standard
Interlocked socket-outlets IEC 309 standard
System of industrial socket-outlets for power distribution in the industrial and commercial sector, equipped with locking device, enabling the most varied professional requirements of installers and panel builder to be met. The IB range is composed of 4 product lines: IP67 standard vertical socket-outlets, IP66 vertical socket-outlets for heavy duty applications, IP44 horizontal socket-outlets and IP44 and IP55 compact socket-outlets.
125 °C (active parts) - 80 °C (passive parts)
IP44
IK08
850 °C (active parts) - 650 °C (passive parts)
Technical Info
Information
Download
Software
Certificates
Type
Horizontal
Thermo-pressure with ball
125 °C (active parts) - 80 °C (passive parts)
IP degree
IP44
No. of poles
2P+E
Mechanical resistance
IK08
Frequency
50/60 Hz
Operating temperature
-25 +40 °C
Protection
NO (SBF)
With back-mounting box
Yes
Electrocod
2220
Glow wire test
850 °C (active parts) - 650 °C (passive parts)
Colour
Red
Rated current (A)
16
Reference h
9
Rated voltage
380-415 V
Ware Number
85366990
EQUIPMENT AND NOTES
ACCESSORIES SUPPLIED: coupling for Ø 20 mm conduits and Ø 23 mm cable gland.
